Terminations

Qualwave supplies broadband and high power coaxial terminations cover the frequency range DC~67GHz. The average power handling is up to 500 watts. The terminations are widely used in many applications.

Features:
  • Low VSWR
  • High Power
  • Broadband
Applications:
  • Transmitters
  • Antennas
  • Laboratory Test
  • Impedance Matching
Terminations
Part Number Frequency (GHz) Power (W) VSWR (Max.) Connectors Lead Time (weeks)
QCT67R5 DC~67 0.5 1.45 1.85mm 0~4
QCT6702 DC~67 2 1.8 1.85mm 0~4
QCT50R5 DC~50 0.5 1.4 2.4mm 0~4
QCT5002 DC~50 2 1.4 2.4mm 0~4
QCT5005 DC~50 5 1.4 2.4mm 0~4
QCT40R5 DC~40 0.5 1.5 2.92mm, SSMA, SMP, SSMP 0~4
QCT4002 DC~40 2 1.5 2.92mm, SSMA, SMP, SSMP 0~4
QCT4005 DC~40 5 1.35 2.92mm 0~4
QCT4010 DC~40 10 1.35 2.92mm 0~4
QCT4020 DC~40 20 1.35 2.92mm 0~4
QCT4050 DC~40 50 1.35 2.92mm 0~4
QCT33R5 DC~33 0.5 1.25 3.5mm 0~4
QCT3302 DC~33 2 1.15 3.5mm 0~4
QCT2602 DC~26.5 2 1.25 SMA 0~4
QCT2605 DC~26.5 5 1.3 3.5mm, SMA 0~4
QCT2610 DC~26.5 10 1.3 3.5mm, SMA 0~4
QCT2625 DC~26.5 25 1.3 3.5mm, SMA 0~4
QCT2650 DC~26.5 50 1.3 3.5mm, SMA 0~4
QCT26K1 DC~26.5 100 1.4 SMA 0~4
QCT1801 DC~18 1 1.25 SMA, SSMA 0~4
QCT1802 DC~18 2 1.4 N 0~4
QCT1805 DC~18 5 1.4 N, SMA 0~4
QCT1810 DC~18 10 1.4 N, SMA 0~4
QCT1820 DC~18 20 1.4 N, SMA 0~4
QCT1850 DC~18 50 1.4 N, SMA 0~4
QCT18K1 DC~18 100 1.35 N, SMA 0~4
QCT18K15 DC~18 150 1.45 N 0~4
QCT18K2 DC~18 200 1.4 N 0~4
QCT18K25 DC~18 250 1.4 N 0~4
QCT18K3 DC~18 300 1.45 N 0~4
QCT18K5 DC~18 500 1.6 N 0~4
